How to easily draw a Rectangle with a fillet angle in AutoCAD?
When working with drawings in AutoCAD, it may be necessary to create a rectangle with rounded corners to represent certain objects, areas, or structures. However, doing so manually can be a time-consuming process, requiring the use of several commands like rectangle, fillet, and trim.
Drawing a rectangle with a fillet angle in AutoCAD can be made easier through the use of a simple LISP code. In this post, I will guide you on how to utilize a LISP code that can draw a rectangle with any fillet angle size and orientation in just one click.
What is the AutoCAD LISP and how do you upload it to AutoCAD?
After you have uploaded the LISP file, you can type 'REC' to activate it.
Pick the other corner.
Finally, enter the corner round radius.
You can download the lisp from here.
Conclusion:
If you are using AutoCAD and you want to save time and effort when working with drawings, you can try using this LISP code. With a single click, you can draw a rectangle with a fillet angle, without having to use the rectangle command, the fillet command, and the trim command. This LISP code is also useful if you want to create uniform and consistent rectangles with a fillet angle, especially if you need to adhere to a certain standard or preference.
In this post, I have demonstrated how to draw a rectangle with a fillet angle in AutoCAD using a LISP code. This tool can significantly improve your productivity and the quality of your work when working with drawings in AutoCAD. I hope you found this post informative and helpful. If you have any questions or feedback, please feel free to leave a comment below. Thank you for reading.
